Foscam C1 User Manual

82
Network Protocol
IP、TCP、UDP、HTTP、HTTPS、SMTP、FTP、DHCP、DDNS、
UPnP、RTSP、WPS
Remote Access
P2P, DDNS
System
Requirements
Operating System
Microsoft Windows XP, Vista, 7, 8;
Mac OS
iOS、Android
Browser
Microsoft IE8 and above version or compatible browser;
Mozilla Firefox;
Google Chrome;
Apple Safari.
Other
Features
Motion Detection
Alarm via E-Mail, upload alarm snapshot to FTP
PIR
Infrared human body sensor
User Accounts
Three levels user role
Firewall
Supports IP Filtering
Storage
32G Micro SD card, local and FTP storage
Reset
Reset button is available
Power
Power Supply
DC 5V/1.0A
Power Consumption
4.5W（Max）
Physical
Dimension(LxWxH)
70*70*120mm
Net Weight
170g
Environment
Operating Temperature
-10°C ~ 50°
(14°F ~ 122°F)
Operating Humidity
20% ~ 85% non-condensing
Storage Temperature
-20°C ~ 60° (-4°F ~ 140°F)
Storage Humidity
0% ~ 90% non-condensing
Certification
CE, FCC, RoHS
Warranty
Limited 2-year warranty
ITEMS
R2
Image Sensor
Sensor Type
1/3'' CMOS
Display Resolution
1920 x 1080 (2.0 Megapixels)
Frame Rate
30fps
Min. Illumination
0 Lux (With IR Illuminator)
Lens
Lens Type
f:2.8mm,F:2.6
Angle of View
Horizontal:90°
Diagonal :110°
Night Vision
13pcs IR-LEDs, night vision range up to 8 metres
Video
Image Compression
H.264
Resolution
1080P(1920x1080),720P(1280 x 720), VGA(640 x 480),
QVGA(320 x 240)

Foscam C1 Specifications

General

Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Form factor	-
Mounting type	Desk/Ceiling
Product color	Black
Maximum resolution	1280 x 720 pixels
Video formats supported	H.264
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/4 \
Motion sensor	Yes
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Night vision distance	8 m
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11d, IEEE 802.11g, IEEE 802.11n
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Power consumption (typical)	3 W
Sustainability certificates	RoHS
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	120 mm
Width	70 mm
Weight	170 g
