Foscam C1 User Manual

81
Subnet mask: obtain dynamically
Gateway: obtain dynamically
DDNS: Embedded FOSCAM domain name
Username and password
Default admin username: admin with a blank password
6.3 Specifications
ITEMS
C1
Image Sensor
Sensor
High Definition Color CMOS Sensor
Display Resolution
1280 x 720 (1Megapixels)
Min. Illumination
0 Lux (With IR Illuminator)
Lens
Lens Type
Glass Lens
focal length
f:2.8mm
Aperture
F2.4
Diagonal angle of view
115°
Horizontal view angle
100°
Video
Image Compression
H.264
Image Frame Rate
25fps（VGA）, 23fps（720P）, downward adjustable
Resolution
720P(1280 x 720), VGA(640 x 480), VGA(640 x 360),
QVGA(320 x 240), QVGA(320 x 180)
Stream
dual stream
Image adjustment
The hue, brightness, contrast, saturation, sharpness are
adjustable
Flip image
flip and mirror
Infrared mode
Automatic or manual
manual Pan/Tilt Angle
Horizontal:350° & Vertical: 180°
Night visibility
11pcs IR-LEDs, night vision range up to 8 metres
Audio
Input/Output
Supports two-way audio
Built-in Mic & Speaker
Audio Compression
PCM/G.726
Network
Ethernet
One 10/100Mbps RJ45 port
Wireless Standard
IEEE802.11b/g/n
Data Rate
IEEE802.11b: 11Mbps(Max.);
IEEE802.11g: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.).
Wireless Security
WEP, WPA, WPA2
WPS
Supports EZLink wireless setup

Foscam C1 Specifications

General

Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Form factor	-
Mounting type	Desk/Ceiling
Product color	Black
Maximum resolution	1280 x 720 pixels
Video formats supported	H.264
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/4 \
Motion sensor	Yes
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Night vision distance	8 m
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11d, IEEE 802.11g, IEEE 802.11n
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Power consumption (typical)	3 W
Sustainability certificates	RoHS
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	120 mm
Width	70 mm
Weight	170 g
