Maintenance/Specifications
Maintenance
Specifications
Cleaning the exterior
* For normal cleaning, use a soft dry cloth
For stubborn dirt, moisten a cloth in diluted detergent, wring it out firmly, and wipe the dirt off. Then polish with a dry
cloth.
Never use solvents such as alcohol, thinner or benzene, since these will damage the printing and finish of the exterior.
* Mixer section
<INPUT 1 ~ 6>
Connector : 6mm Phone jack (x 6)
Input Impedance : 20k
or higher
Reference Input Level : -10dBV
<INPUT 7, 8>
Connector : 6mm Phone jack (x 2)
: XLR-3-31 type (x 2)
Input Impedance : 20k
or higher
Reference Input Level : L: -50dBV, M: -30dBV,
H: -10dBV
<INSERT 7, 8>
Connector : 6mm Phone jack (x 2)
Load Impedance : 10k
or higher
Reference Output Level : -10dBV
Input Impedance : 10k
or higher
Reference Input Level : -10dBV
<AUX SEND 1, 2>
Connector : 6mm Phone jack (x 2)
Load Impedance : 10k
or higher
Reference Output Level : -10dBV
<AUX RTN 1 L/R, 2 L/R>
Connector : 6mm Phone jack (x 4)
Input Impedance : 8k
or higher
Reference Input Level : -20dBV
<STEREO OUT L/R>
Connector : RCA pin jack (x 2)
Load Impedance : 10k
or higher
Reference Output Level : -10dBV
<MONITOR OUT L/R>
Connector : 6mm Phone jack (x 2)
Load Impedance : 10k
or higher
Reference Output Level : -10dBV
<PHONES OUT>
Connector : 6mm Stereo Phone jack
Load Impedance : 16
or higher
Maximum output : 50mW (at 50
)
<Equalizer>
HI : 12kHz +/-15dB (Shelving type)
MID : 200Hz ~ 5kHz +/- 15dB (Parametric type)
LO : 80Hz +/- 15dB (Shelving type)
<Frequency Response> : 20Hz ~ 20kHz (typical)
<Dynamic Range> : 105dB (typical)
* Recorder section
<Recording/Reproducing>
Recording Medium : External SCSI device
(SCSI-2, asymmetrical transfer)
* Connectable SCSI device: Two (for recording
x1, for backup x 1)
: Internal E-IDE type 2.5 inch
hard disk (optional)
<Recording Format> : FDMS-3*
(* Fostex Disk Management System-3)
<Recording Mode>
Normal Mode : 8 Real track + 16 Additional
track (Sampling Rate: 44.1kHz/
A.D.A.C.*)
Mastering Mode : 8 Real track + 16 Additional
track (Sampling Rate: 44.1kHz/
16-bit linear)
<A/D> : 20-bit 64 times over sampling,
delta sigma modulation type
<D/A> : 20-bit 128 times over
sampling, delta sigma
modulation type
<Digital Input/Output> : 44.1kHz/16-bit linear
<Save/Load> : Mastering Mode: FDIO-1*
(DAT, adat)
: Normal Mode: SCSI
(* Fostex Data Input /Output-)1
