Fourgroup Full-App 2 - 11. SETTINGS PUMPS; Pump 1 Alarm Delay Settings (Current;Cosø); Max Continuous Working Alarm Configuration

23
To move to the next horizontal parameter press the button
:
To move to the next horizontal parameter press the button
:
To move to the next horizontal parameter press the button
:
The parameter “P1 Alarm Delay I max” will set the time delay for the activation of the alarm
for maximum current consumption (overcurrent): the threshold must be crossed (overcurrent)
for the amount of time specified for the alarm to trigger and to stop the pump.
For example, if the alarm time delay is set to 10 seconds then the threshold is crossed
continuously for 10 seconds for the alarm to activate; if the threshold is crossed for less than
10 seconds alarm will not activate.
The “X” indicates the setting of the parameter to modify.
The range of value is from 5 to 15 seconds.
Factory default setting: 5 seconds.
Configuration
Pump1
P1 Alarm Delay
IMax XXsec
P1 Alarm Delay
IMin XXsec
P1 Alarm Delay
IMax XXsec
P1 Alarm Delay
Cosφ XXsec
P1 Alarm Delay
IMin XXsec
The parameter “P1 Alarm Delay I min” will set the time delay for the activation of the alarm for
minimum current consumption (undercurrent): the threshold must be crossed (undercurrent)
for the amount of time specified for the alarm to trigger and to stop the pump.
For example, if the alarm time delay is set to 10 seconds and the threshold is crossed
continuously for 10 seconds for the alarm to activate; if the threshold is crossed for less than
10 the alarm will not activate.
The “X” indicates the setting of the parameter to modify.
The range of value is from 1 to 120 seconds.
Factory default setting: 3 seconds.
P1 Alarm Delay
Cosφ XXsec
P1 Alarm Delay
IMin XXsec
Enable Max Cont.
Working 0=NO X
P1 Alarm Delay
Cosφ XXsec
The parameter “P1 Alarm Delay Cosφ” will set the time delay for the activation of the alarm for
minimum Cosφ (the lowering of the Cosø value is an indication that the pump is not sucking
water and it’s working in dry condition): the threshold must be crossed (dry running condition)
for the amount of time specified for the alarm to trigger and to stop the pump.
For example, if the alarm time delay is set to10 seconds and the threshold is crossed
continuously for 10 seconds for the alarm to activate; if the threshold is crossed for less than
10 seconds the alarm will not activate.
The “X” indicates the setting of the parameter to modify.
The range of value is from 1 to 120 seconds.
Factory default setting: 3 seconds.
Enable Max Cont.
Working 0=NO X
P1 Alarm Delay
Cosφ XXsec
Enable Max Start
Minute 0=NO X
Enable Max Cont.
Working
0=NO X
The parameter “Enable Max Continuous working operation” will enable/disable the alarm for the
maximum continuous operation of the pump. When enabled and the pump is continuously
working for a period of time over the value set then the alarm will be activated and the pump
will be stopped. The functional operation of the pump will be inhibited until the reset of the
alarm (pressing the button
of the pump in “status of alarm”).
The “X” indicates the setting of the parameter to modify.
0=NO: setting “0” will disable the alarm for max continuous working condition of the pump.
1=YES: setting “1” will enable the alarm for max continuous working condition of the pump.
Factory default setting: 0 (disable).
