Fourgroup Full-App 2 - 12. OPERATING PROGRAMS; Pump 1 Operating Mode Selection; Pump 2 Operating Mode Selection; Enable MULTITANK Operating Mode

32
To move to the next horizontal parameter press the button
:
To move to the next horizontal parameter press the button
:
The setting of all the parameters for the program operating mode MULTITANK is complete.
Refer to section “INSTALLATION EXAMPLES” for directions of the connections and the applications of the mode
MULTITANK.
At this point the horizontal menu “Operation Programs” has been fully programmed and you can proceed to the next
menu.
To go back to the horizontal menu “Operation Programs” press the button
.
Press the button
to move to the next horizontal menu “GSM Modem Setting”
With the parameter “Operation Mode Pump 1” it is possible to select one of the following modes
for pump 1:
1=Operating mode CLEAN – EMPTY
2=Operating mode CLEAN – FILL
3=Operating mode DARK – EMPTY
4=Operating mode DARK – FILL
5=Operating mode DIGIT – EMPTY
6=Operating mode DIGIT – FILL
The “X” indicates the setting of the parameter to modify.
Factory default setting: 1 (CLEAN – EMPTY).
Program
MULTITANK
Operation Mode
Pump 1 1-6 X
Operation Mode
Pump 2 1-4 X
Operation Mode
Pump 1 1-6 X
Operation Mode
Pump 2 1-4 X
With the parameter “Operation Mode Pump 2” it is possible to select one of the following modes
for pump 1:
1=Operating mode CLEAN – EMPTY
2=Operating mode CLEAN – FILL
3=Operating mode DARK – EMPTY
4=Operating mode DARK – FILL
The “X” indicates the setting of the parameter to modify.
Factory default setting: 1 (CLEAN – EMPTY).
NOTE: for pump 2 the operating mode DIGIT is not available.
NOTE: the setting of the alarm level/pressure and commands of the pumps of operating mode
MULTITANK are under the submenu “Enable 4-20 mA” of the menu “General Settings”. In addition, it is
necessary to set the parameters “Stop Level P1” and “Start Level P1”.
Enable
MULTITANK
Operation Mode
Pump 2 1-4 X
Enable
MULTITANK
The parameter “Enable MULTITANK” will enable/disable the operating mode MULTITANK. The
mode MULTITANK recognises the operating settings of the pumps installed.
To enable the operating mode MULTITANK press the button
to save its setting. The display
will show briefly the message “save” as confirmation that the setting has been saved. In the
main display the word “mlt” will show to indicate the selected program operating mode.
Operating
Programs
Settings
Pumps
GSM Modem
Setting
