Fourgroup Full-App 2 - 12. OPERATING PROGRAMS; Enable CLEAN Operating Mode; DIGIT Mode Empty;Fill Setting; Enable DIGIT Operating Mode

31
To move to the next horizontal parameter press the button
:
The setting of all the parameters for the program CLEAN operating mode is complete.
Refer to section “INSTALLATION EXAMPLES” for directions of the connections and the applications of the mode CLEAN.
Similarly of the previous program operating mode, it is possible to select “Program DIGIT” and set all its parameters.
To proceed and set all the parameters of the operating mode DIGIT press the button
:
To move to the next horizontal parameter press the button
:
The setting of all the parameters for the program operating mode DIGIT is complete.
Refer to section “INSTALLATION EXAMPLES” for directions of the connections and the applications of the mode DIGIT.
Similarly of the previous program operating mode, it is possible to select “Program MULTITANK” and set all its
parameters.
To proceed and set all the parameters of the operating mode MULTITANK press the button
:
Enable
CLEAN
Operating mode
Empty/Fill X
Enable
CLEAN
The parameter “Enable CLEAN” will enable/disable the program operating mode Clean. Once
enabled the mode CLEAN it will apply to all the installed pumps.
To enable the operating mode Clean press the button
to save its setting. The display will
show briefly the message “save” as confirmation that the setting has been saved. In the main
display the word “cln” will show to indicate the selected program operating mode.
Factory default setting: CLEAN enable.
The parameter “Operating mode Empty/Fill” will set the mode of the program “Digit” to “empty”
or “fill”. Typically with “Empty” the 4-20 mA devices are inside the tank in which the pump is
installed. Typically, with “Fill” the 4-20 mA devices are in a different tank from which the pumps
are installed.
The “X” indicates the setting of the parameter to modify.
0=EMPTY
1=FILL
Factory default setting: 0 (Empty).
Program
DIGIT
Operating mode
Empty/Fill X
Enable
DIGIT
Operating mode
Empty/Fill X
Enable
DIGIT
The parameter “Enable DIGIT” will enable/disable the program operating mode DIGIT. Once
enable the mode DIGIT it will apply to all the installed pumps.
To enable the operating mode DIGIT press the button
to save its setting. The display will
show briefly the message “save” as confirmation that the setting has been saved. In the main
display the word “Dig” will show to indicate the selected program operating mode.
NOTE: the setting of the alarm level/pressure and commands of the pumps of operating mode DIGIT are
under the submenu “Enable 4-20 mA” of the menu “General Settings”. The setting of the level/pressure
needs to be consistent with the logical of operating mode selection (empty or fill).
