27
3
Award (Phoenix) BIOS can support 3 HDD modes: CHS, LBA and Large.
Note: Set to [Auto] , the system can detect the hard disk and select the HDD mode automati-
cally. Suggest you select this option.
The SATA Port information will not be displayed if "SATA Mode" is set to [AHCI] or [RAID]. In
these two modes, the hard disk information can be found by getting into Intel
®
Matrix Storage
Manager option ROM utility (or RAID BIOS). We will discuss RAID BIOS later.
► Drive A
This option allows you to select which kind of the Floppy Disk Drive is installed in your system.
It can be [360KB, 5.25in], [1.2MB, 5.25in], [720KB, 3.5in], [1.44MB, 3.5in] and [2.88 MB, 3.5in].
► Halt On
This category determines whether or not the computer will stop if an error is detected during
powering up.
All Errors Whenever the BIOS detects a nonfatal error, the system will stop
and you will be prompted.
No Errors The system boot will not stop for any errors that may be
detected.
All, But Keyboard The system boot will not stop for a keyboard error; but it will stop
for all other errors.
All, But Diskette The system boot will not stop for a diskette error; but it will stop
for all other errors.
All, But Disk/Key The system boot will not stop for a keyboard or disk error, but it
will stop for all other errors.
CHS For HDD <528MB
LBA For HDD >528MB & Supporting LBA (Logical Block Addressing)
Large For HDD>528MB but not supporting LBA
