Power
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Advanced Chipset Boot Power Health Security Save & Exit
ACPI Sleep State [S3]
Resume By PS2 Keyboard [Enabled]
Resume By PS2 Mouse [Enabled]
Resume By Onboard LAN [�isabled]
Resume By USB �evice(s) [Enabled]
Resume By PCIE PME [�isabled]
Resume By RTC [�isabled]
Energy-using Products [Enabled]
Restore AC Power Loss [Power Off]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized �efaults
F4: Save & Exit
ESC: Exit
Select the highest ACPI sleep
state the system will enter
when the SUSPEN� button is
pressed.
Power
► ACPI Sleep State
This item is used to set the energy saving mode of the ACPI function. When you select “S1
(POS)” mode, the power is always on and computer can be resumed at any time. When
you select “S3 (STR)” mode, the power will be down after a period of time. The status of the
computer before it entering STR will be saved in memory, and the computer can quickly return
to previous state when the STR function wakes.
► Resume by PS2 Keyboard
This item is used to enable/disable the PS2 keyboard to generate a wake up.
► Resume by PS2 Mouse
This item is used to enable/disable the PS2 mouse to generate a wake up.
► Resume by Onboard LAN
This item is used to enable/disable the onboard LAN to generate a wake up.
► Resume by USB Device(s)
This item is used to wake up the system by a USB device when it is staying at S3 state.
► Resume by PCIE PME
This item is used to enable/disable the PCI Express device to generate a wake up.
► Resume by RTC
This item is used to enable/disable RTC alarm event to generate a wake up.
RTC is system real time clock.
► RTC Alarm Date(Days)
WhenResumebyRTCisenabled,selectaspecicdatetogenerateawakeup.
► RTC Alarm Time(HH:MM:SS)
WhenResumebyRTCisenabled,selectaspecictimetogenerateawakeup.
► Energy-using Products
This item is used to enable/disable the EuP(Energy-using Products) feature. When enable, the
suspendpowerofthechipsetwillbecutoffinS5suspendmodeinordertoreducethepower
consumption of motherboard.
Enabled:S1/S3/S4isnormal,S5wakeuponlybypressingthepowerbutton.
