Foxconn H67MP series User Manual

1
2
1-1 Product Specications
CPU SupportLGA1155socketIntel®CPU,Maxprocessorpowerupto95W
For the latest CPU information, please visit：
http://www.foxconnsupport.com/cpusupportlist.aspx
Chipset Intel
®
H67
Memory 4x240-pinDDR3DIMMs
Support up to 32GB of system memory
DualchannelDDR31333/1066MHzarchitecture
Expansion Slots 2 x PCI Express x16 slot (PCI-E1_16X2onlysupportPCIExpressx4speed)
2 x PCI Express x1 slotsPCI Express x1 slots
Storage H67 chipset:
-2xSATA3.0connectors600MB/sdatatransferrate
-4xSATA2.0connectors300MB/sdatatransferrate
-SupportRAID0,1,5and1010
- Support hot plug and NCQ (Native Command Queuing )
LAN Realtek 8111E Gigabit LAN chipGigabit LAN chip
Audio Realtek ALC887 (H67MP-S/H67MP)/ALC662 (H67MP-V) audio chip: ALC887 (H67MP-S/H67MP)/ALC662 (H67MP-V) audio chip:(H67MP-S/H67MP)/ALC662 (H67MP-V) audio chip:/ALC662 (H67MP-V) audio chip:(H67MP-V) audio chip: audio chip:
-HighDenitionAudio
-2/4/5.1/7.1(H67MP-S/H67MP)-channel
- Support for S/PDIF Out
- Support Jack-Sensing function
USB H67 chipset:
-Supportupto12xUSB2.0ports(6rearpanelports,3onboardUSB
headers supporting 6 extra ports)
NEC chipset:
-Supportupto2xUSB3.0ports(H67MP-S)
Internal Connectors 1x24-pinATXmainpowerconnector
1x4-pinATX12Vpowerconnector
4xSATA2.0connectors
2xSATA3.0connectors
3xUSB2.0connectors(supporting6xUSBdevices)
1xCPUfanheader(4-pin)
1xSystemfanheader(4-pin)
1 x Front panel connector
1 x CD_IN connector
1 x Front Audio connector
1 x SPDIF_OUT connector
1 x Speaker connector
1 x Chassis intrusion alarm header
(Continued on the next page)
