Foxconn H67MP series User Manual

5
81
A message will appear :
Press<Y>tocreatethevolumeandreturntothemainmenu.TwoRAID0volumes
werecongured.
Are you sure you want to create this volume ? (Y/N) :
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
1. Create RAID Volume 3. Reset Disks to Non-RAID
2.DeleteRAIDVolume  4.RecoverVolumeOptions
   5.Exit
RAID Volume :
ID Name Level Stripe Size Status Bootable
 0 TryRAID0  RAID0(Stripe)128KB150.0GB Normal Yes
 1 TryRAID0-1  RAID0(Stripe)128KB148.1GB Normal Yes
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
 0 Hitachi HDS72161 PVF904�21G2J�M 149.0GBHitachiHDS72161 PVF904�21G2J�M 149.0GB PVF904�21G2J�M 149.0GB MemberDisk(0,1)
1 ST380811AS 5PS1TAGW 74.5GB Non-RAID Disk
2 SAMSUNG HD161HJ  S0V3J9APA30524 149.0GBS0V3J9APA30524 149.0GB 149.0GB MemberDisk(0,1)
3 ST380815AS 5RW1CA37  74.5GB Non-RAID Disk
Intel(R)RapidStorageTechnology-OptionROM-10.0.0.1032
Copyright(C)2003-10IntelCorporation.AllRightsReserved.
[ DISK/VOLUME INFORMATION ]
[ MAIN MENU ]
1. Create RAID Volume
[↑↓]-Select[ESC]-Exit[ENTER]-SelectMenu
