Foxconn H67MP series User Manual

5
84
6. It will skip “Strip Size” menu for RAID1.
7. In “Capacity” item, use the default value, and press <Enter>. The size of the smaller
harddisk74.5GBisbecomingthedefaultvalue,anditindicatesthemaximum
capacity.
8. Select “Create Volume” and press <Enter>. A warning message will appear:
Press <Y> to create the volume and return to the main menu.
WARNING: ALL DATA ON SELECTED DISKS WILL BE LOST.
Are you sure you want to create this volume ? (Y/N) :
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
The default value indicates the maximum capacity using the selected
disks. Entering a lower capacity allows you to create a second
volume on these disks
Intel(R)RapidStorageTechnology-OptionROM-10.0.0.1032
Copyright(C)2003-10IntelCorporation.AllRightsReserved.
Name:
RAID Level:
Disks:
Strip Size:
Capacity:
Sync:
TryRAID1
RAID1(Mirror)
Select Disks
N/A
74.5GB
N/A
Create Volume
[↑↓]-Change[TAB]-Next[ESC]-PreviousMenu[ENTER]-Select
[ HELP ]
74.5
[ CREATE VOLUME MENU ]
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
1. Create RAID Volume 3. Reset Disks to Non-RAID
2.DeleteRAIDVolume  4.RecoverVolumeOptions
  5.Exit
RAID Volume :
ID Name Level Stripe Size Status Bootable
 0 TryRAID1  RAID1(Mirror)N/A 74.5GB Normal Yes
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
 0 Hitachi HDS72161 PVF904�21G2J�M 149.0GBHitachiHDS72161 PVF904�21G2J�M 149.0GB PVF904�21G2J�M 149.0GB MemberDisk(0)
1 ST380811AS 5PS1TAGW 74.5GB MemberDisk(0)
2 SAMSUNG HD161HJ  S0V3J9APA30524 149.0GBS0V3J9APA30524 149.0GB 149.0GB Non-RAID Disk
3 ST380815AS 5RW1CA37  74.5GB Non-RAID Disk
Intel(R)RapidStorageTechnology-OptionROM-10.0.0.1032
Copyright(C)2003-10IntelCorporation.AllRightsReserved.
[ DISK/VOLUME INFORMATION ]
[ MAIN MENU ]
1. Create RAID Volume
[↑↓]-Select[ESC]-Exit[ENTER]-SelectMenu
