Mapping Tabe:
With PATA IDE drives Without PATA IDE drives
With PATA IDE
drives
IDE Conguration IDE Conguration IDE Conguration
SATA#1 Conguration
Compatible/Enhanced
SATA#1 Conguration
Disabled
SATA#1 Conguration
Compatible/Enhanced
SATA#1 Conguration
Disabled
Congure
SATA#1 as
SATA#2 Conguration SATA#2 Conguration SATA#2 Conguration SATA#2 Conguration
RAID AHCI
Enhanced Disabled Enhanced Disabled Enhanced Disabled Enhanced Disabled
Primary IDE Master SATA 1 SATA 1 SATA 5 ESATA1 SATA 1 SATA 1 SATA 5 ESATA1 ESATA1 ESATA1
Primary IDE Slave SATA 3 SATA 3 - ESATA2 SATA 3 SATA 3 - ESATA2 ESATA2 ESATA2
Secondary IDE Master SATA 2 SATA 2 SATA 6 IDE0 SATA 2 SATA 2 SATA 6 - IDE0 IDE0
Secondary IDE Slave SATA 4 SATA 4 - IDE1 SATA 4 SATA 4 - - IDE1 IDE1
Third IDE Master SATA 5 ESATA1 ESATA1 - SATA 5 ESATA1 ESATA1 - - -
Third IDE Slave - ESATA2 ESATA2 - - ESATA2 ESATA2 - - -
Forth IDE Master SATA 6 IDE0 IDE0 - SATA 6 - - - - -
Forth IDE Slave - IDE1 IDE1 - - - - - - -
Fifth IDE Master ESATA1 - - - ESATA1 - - - - -
Fifth IDE Slave ESATA2 - - - ESATA2 - - - - -
Sixth IDE Master IDE0 - - - - - - - - -
Sixth IDE Slave IDE1 - - - - - - - - -
