Advanced Chipset Features
► NB Revision/Current QPI Frequency
It displays the NB Revision and current QPI frequency.
► USB Functions
This item is used to select how many USB ports are available.
► USB Port Configure
This item is used to congure USB Ports. Options are: [6x6 USB Ports] and [8x4 USB ports].
► USB 2.0 Controller
This item is used to enable or disable the Enhanced Host Controller Interface for USB.
PCIE Ports Configuration
► PCIE Port 3
This item is used to enable/disable the PCIE Port 3 function. Select [Auto], OS will automatically
determine wether to enable PCIE Port 3 function.
► PCIE Port 4
This item is used to enable/disable the PCIE Port 4 function. Select [Auto], OS will automatically
determine wether to enable PCIE Port 4 function.
► PCIE High Priority Port
This item is used to select which PCIE port will be used as the the high priority port.
CMOS Setup Utility - Copyright (C) 1985-2008, American Megatrends, Inc.
Advanced Chipset Features
Advanced Chipset Settings Help Item
NB Revision :B2
Current QPI Frequency :4.800GT
WARNING:Setting wrong values in below sections Disabled
may cause system to malfunction. 2 USB Ports
4 USB Ports
USB Functions [12 USB Ports] 6 USB Ports
USB Port Configure [6X6 USB Ports] 8 USB Ports
USB 2.0 Controller [Enabled] 10 USB Ports
12 USB Ports
PCIE Ports Configuration
PCIE Port 3 [Auto]
PCIE Port 4 [Auto]
PCIE High Priority Port [Disabled]
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[12 USB Ports]
Options
