SuperIO Conguration
► IrDA Address
This item is used to assign the I/O address and interrupt request (IRQ) for the onboard infra-
red device.
► IrDA Mode
This item is used to select the IR mode. The available settings are:
[IrDA (1.6us)]: An IrDA device for maximum 115200 bit/s.
[IrDA (3/16 bit)]: A faster IrDA for 1152000 bit/s.
► IR Duplex Mode
This item enables you to determine the transfer mode of the onboard infrared chip. Setting
values are: [Full Duplex], [Half Duplex].
► IRTX Pin Select
This item allows BIOS to Select Transmit pin is in normal condition or inverse the IRTX (IR
Mode).
► IRRX Pin Select
This item allows BIOS to Select Receiver pin is in normal condition or inverse the IRRX (IR
Mode).
► IR Tx to Rx Delay Select
This item allows BIOS to Select IR from Tx to Rx 4 charactersTime Delay. (IR Mode)
► IR Rx to Tx Delay Select
This item allows BIOS to Select IR from Rx to Tx 4 charactersTime Delay. (IR Mode)
CMOS Setup Utility - Copyright (C) 1985-2008, American Megatrends, Inc.
SuperIO Conguration
Configure F71883FG Super IO Chipset Help Item
IrDA Address [2F8/IRQ3]
IrDA Mode [IrDA (1.6us)]
IR Duplex Mode [Half Duplex]
IRTX Pin Select [Normal]
IRRX Pin Select [Normal]
IR Tx to Rx Delay Select [No Delay]
IR Rx to Tx Delay Select [No Delay]
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
Options
[2F8/IRQ3]
