Part No.21967 Rev. M June 2017 - 24 - Refrigerated Well GN Series
SERVICING
Control Gear
GN SERIES REFRIGERATED WELL
-
SERVICING
The control gear is located
inside the control panel
assembly.
A miniature circuit breaker,
MCB, protects the low power
circuits and the power feed to
the optional lighting gantry.
Mains Lead
GN SERIES REFRIGERATED WELL
-
SERVICING
If damaged, the mains lead must ONLY be replaced by a qualified service
person.
Refrigeration
GN SERIES REFRIGERATED WELL
-
SERVICING
DO NOT attempt to service the refrigeration equipment without isolating
the cabinet at the main switch or unplugging it from the wall.
Access to
Compressor
etc.
To gain access to the
refrigeration compressor,
condenser radiator etc., the
access panels must first be
removed from the joinery.
The metal grills should then
be removed to reach the
refrigeration equipment.
Continued on next page
