FPG Inline GN Series - Specifications; Mechanical; Electrical

Part No.21967 Rev. M June 2017 - 34 - Refrigerated Well GN Series
SPECIFICATIONS
Mechanical
GN SERIES REFRIGERATED WELL - SPECIFICATIONS
CABINET MODEL
IN-GNC03
IN-GNC04
IN-GNC05
IN-GNC06
Height mm
768
768
768
768
Width mm
1320
1660
2000
2340
Depth mm
805
805
805
805
Dry Weight
130 kg
140 kg
160 kg
190 kg
Well Material
Stainless Steel
Drain tube diameter
19 mm
Display Area
0.53 m
2
0.70 m
2
0.87 m
2
1.04 m
2
Refrigerant
R134A
R134A
R134A
R134A
Refrigerant Charge
320 g
340 g
500 g
780 g
Climatic Class & IP
All wells are suitable for class N climates and have an IP 22 rating
Electrical
GN SERIES REFRIGERATED WELL - SPECIFICATIONS
CABINET MODEL
IN-GNC03
IN-GNC04
IN-GNC05
IN-GNC06
Voltage
230 - 240 V
50 Hz 1
230 - 240 V
50 Hz 1
230 - 240 V
50 Hz 1
230 - 240 V
50 Hz 1
Power (without gantry)
0.8 kW
1.0 kW
1.1 kW
1.2 kW
Extra boil-off power
1.0kW
1.0kW
1.0kW
1.0kW
Current (without gantry)
2.5 A
4.0 A
4.4 A
4.6 A
Extra boil-off current
4.0A
4.0A
4.0A
4.0A
Connection
3-core cable & 10A 3-pin plug
Overhead Lights
Optional Gantry
Optional Gantry
Optional Gantry
Optional Gantry
