IN-GNC03/4/5/6 - 35 - © Future Products Group
Controller Settings
GN SERIES REFRIGERATED WELL
-
SPECIFICATIONS
Changes from
Dixell Defaults
The following table specifies the controller settings which differ from the Dixell
default values.
Parameters not listed in this table should remain at the default values specified
in the XR40CZ Parameters listed in the Servicing section.
XR40CX Settings
Parameter
Description
Settings for Models
Units/Range
IN-
GNC0
3
IN-
GNC0
4
IN-
GNC0
5
IN-
GNC0
6
Remote
Versions
Set
Set Point
-6
-6
-6
-6
See left
degC
Hy
Differential
6
6
6
6
See left
degC
P3P
Third Probe Used
Y
Y
Y
Y
N
n=no, Y=yes
AC
Anti Short Cycle Delay
2
2
2
2
See left
Min
C0n
Comp On Time - Faulty Probe
4
4
4
4
See left
Min
C0F
Comp Off Time - Faulty Probe
6
6
6
6
See left
Min
dtE
Defrost Terminate Temp
3
3
3
3
See left
degC
IdF
Interval Between Defrosts
2
2
2
2
See left
Hrs
dFd
Display During Defrost
DEF
DEF
DEF
DEF
See left
rt, it, Set, DEF
ALU
Maximum Temperature Alarm
12
12
12
12
See left
degC
AFH
Differential For Temp Alarm
8
8
8
8
See left
degC
Ald
Temperature Alarm Delay
60
60
60
60
See left
Min
AP2
Probe For High Discharge Temp Alarm
P3
P3
P3
P3
nP
nP, P1, P2, P3, P4
AU2
High Discharge Temp Alarm Set Point
100
100
100
100
See left
degC
AH2
High Discharge Temp Alarm Diff
25
25
25
25
See left
degC
Ad2
High Discharge Temp Alarm delay
0
0
0
0
See left
Min
dA2
High Discharge Alarm Delay At Start
0
0
0
0
See left
Min
AC2
Comp Off For High Discharge Temp Alarm
Y(1)
Y(1)
Y(1)
Y(1)
See left
n(0)=no, Y(1)=yes
