FPG Inline GN Series - FPG Settings; Dixell Default Settings

Part No.21967 Rev. M June 2017 - 30 - Refrigerated Well GN Series
Refrigeration cont.
GN SERIES REFRIGERATED WELL - SERVICING
FPG Settings
Note that the following settings are Dixell factory defaults. Refer to the
Specification section for the correct FPG settings for your cabinet.
Dixell Default
Settings
Label
Name
Range
Default Setting
Set
Set point
LS÷ US
-5.0
Hy
Differential
0,1÷25.5°C/ 1÷ 255°F
2.0
LS
Minimum set point
-50°C÷SET/-58°F÷SET
-50.0
US
Maximum set point
SET÷110°C/ SET ÷ 230°F
110
Ot
Thermostat probe calibration
-12÷12°C /-120÷120°F
0.0
P2P
Evaporator probe presence
n=not present; Y=pres.
Y
OE
Evaporator probe calibration
-12÷12°C /-120÷120°F
0.0
P3P
Third probe presence
n=not present; Y=pres.
n
O3
Third probe calibration
-12÷12°C /-120÷120°F
0
P4P
Fourth probe presence
n=not present; Y=pres.
n
O4
Fourth probe calibration
-12÷12°C /-120÷120°F
0
OdS
Outputs delay at start up
0÷255 min
0
AC
Anti-short cycle delay
0 ÷ 50 min
1
rtr
P1-P2 percentage for regulation
0 ÷ 100 (100=P1 , 0=P2)
100
CCt
Continuous cycle duration
0.0÷24.0h
0.0
CCS
Set point for continuous cycle
(-55.0÷150,0°C) (-67÷302°F)
-5
COn
Compressor ON time with faulty probe
0 ÷ 255 min
15
COF
Compressor OFF time with faulty probe
0 ÷ 255 min
30
CF
Temperature measurement unit
°C ÷ °F
°C
rES
Resolution
in=integer; dE= dec.point
dE
Lod
Probe displayed
P1;P2
P1
rEd2
X-REP display
P1 - P2 - P3 - P4 - SEt - dtr
P1
dLy
Display temperature delay
0 ÷ 20.0 min (10 sec.)
0
dtr
P1-P2 percentage for display
1 ÷ 99
50
tdF
Defrost type
EL=el. heater; in= hot gas
EL
dFP
Probe selection for defrost termination
nP; P1; P2; P3; P4
P2
dtE
Defrost termination temperature
-50 ÷ 50 °C
8
IdF
Interval between defrost cycles
1 ÷ 120 ore
6
MdF
(Maximum) length for defrost
0 ÷ 255 min
30
dSd
Start defrost delay
0÷99min
0
dFd
Displaying during defrost
rt, it, SEt, DEF
it
dAd
MAX display delay after defrost
0 ÷ 255 min
30
Fdt
Draining time
0÷120 min
0
dPo
First defrost after start-up
n=after IdF; y=immed.
n
dAF
Defrost delay after fast freezing
0 ÷ 23h e 50’
0.0
ALc
Temperature alarms configuration
rE= related to set; Ab = absolute
Ab
ALU
MAXIMUM temperature alarm
Set÷110.0°C; Set÷230°F
110
ALL
Minimum temperature alarm
-50.0°C÷Set/ -58°F÷Set
-50.0
Continued on next page
