Framery Q (UL) Meeting Maggie
2. Install the 1 mm adjustment plate into the lower hinge mounting hole and attach half of
both hinges with M6x30 Taptite screws (4 pcs each). Use a hand tool.
Note: Do not use power tools to install the hinges.
Note: Only install the adjustment plate under the lower hinge.
Note: Make sure that the seal is not squashed between the hinge and the door
frame.
Installation instructions
