Framery Q (UL) Meeting Maggie
5.2 Connect the wall modules to the floor
1. Install the guide pins (4 pcs) to the mounting holes of the floor modules.
Note: Make sure that the flat side of the guide pin goes into the mounting hole.
2. Lift one wall module into place.
Note: Make sure that the "This side up" -sticker is on the top edge of the wall.
Note: Support the wall until it is secured with the bolts.
Installation instructions
info@frameryacoustics.com
31
