Framery Q - Page 32

Framery Q (UL) Meeting Maggie
3. Install M8x35 bolts (4 pcs) and M8 washers (4 pcs) and tighten by hand.
Note: Support the wall until it is secured with the bolts.
4. Lift the other wall module into place.
Note: Make sure that the "This side up" -sticker is on the top edge of the wall.
Note: Support the wall until it is secured with the bolts.
32
Installation instructions
