Franke A1000 User Manual

Franke Kaffeemaschinen AG Technical data | 15
User manual A1000 85
15 TECHNICAL DATA
Device type A1000 (FCS4059)
Dimensions: Width/height/depth (mm) 340/540/600
Weight (kg) 58
Bean hopper capacity (kg) 0,6 or 1,2
Twin bean hopper capacity (kg) 2 x 0,6 or 2 x 1,2
Bean hopper capacity, one grinder (kg) 1,8
Powder hopper tall, capacity (kg) 1,2
Powder hopper low, capacity (kg) 0,6
Noise emission (dB(A)) < 70
Ambient temperature (°C) 10-32
Humidity (%) Max. 80
External wastewater tank volume (l) 16
Grounds container capacity (with grounds ejection
option)
60-110 cakes, depending on the grind quantity
Brew boiler Volume (l): 0,9
Operating pressure (bar): 8
Hot water boiler Volume (l): 0,9
Operating pressure (bar): 12
Steam boiler Volume (l): 0,9
Operating pressure (bar): 3
15.1 Capacities in accordance with DIN 18873-2:2016-02
Hourly capacity Single preparation
(cups per hour)
Double preparation
(cups per hour)
Espresso 160 238
Coffee/Café crème 109 141
Hot water (200ml) 164 -
Cappuccino 156 224
Latte macchiato 154 188
Milk coffee 138 188
Chocolate 129 -
15.2 Electrical connection data
Voltage Main power connec-
tion
Power rating (max.) Fuse Frequency
220–240V 1LNPE 5590-7920W 30A 50-60Hz
220–240V 2LPE 4500-5300W 16A 60Hz
380V 3LPE 6300W 16A 60Hz

Franke A1000 Specifications

General

Model	A1000
Brand	Franke
Category	Coffee Maker
Daily Output	Up to 300 cups
Material	Stainless steel
Frequency	50/60 Hz
Dimensions	340 x 600 x 750 mm
Power Supply	220-240 V
Display	touchscreen
