PV series Solar Pumping Inverter
- 26 -
to maximum input of
curve AI1
F06.08
Minimum input of curve
AI2
0.0%～input of inflection point1
of curve AI2
0.0%
△
F06.09
Set value
corresponding
to minimum input of
curve AI2
-100.0～100.0%
0.0%
△
F06.10
Input of inflection point
1 of curve AI2
Minimum input of curve AI1～
Input of inflection point 2 of curve
AI2
100.0%
△
F06.11
Set value
corresponding
to input of inflection
point 1 of curve AI2
-100.0～100.0%
100.0%
△
F06.12
Input of inflection point
2 of curve AI2
Input of inflection point 1 of curve
AI2～ Maximum input of curve
AI2
100.0%
△
F06.13
Set value
corresponding
to input of inflection
point 2 of curve AI2
-100.0～100.0%
100.0%
△
F06.14
Maximum input of curve
AI2
Input of inflection point A of
curve AI2～100.0%
100.0%
△
F06.15
Set value
corresponding
to maximum input of
curve AI2
-100.0～100.0%
100.0%
△
F07 Group: Analog and Pulse Output
F07.00
AO1 Output Function
Selection
0：No Output
1
×
F07.01
AO2 Output Function
Selection
1：Output Frequency
2
×
F07.02
Y2/HO Output Function
Selection
（When used as HO)
2：Set Frequency
1
×
3：Output Current（Inverter Rated
Current）
4：Output Voltage（Inverter Rated
Voltage）
5：Output Power
6：Bus Voltage
7：+10V
8：Keyboard Potentiometer
9：AI1
10：AI2
11：AI3
12：HI Input(100.0%
corresponds 100.00kHz)
