PV series Solar Pumping Inverter
- 40 -
H00.02
Vmpp selection of power
given mode
0：CVT（Constant Voltage appr
Given）
2
×
1：Max Power Point Tracking
（MPPT）
2：Automatic MPPT
0：CVT（Constant Voltage appr Given）
Adopt voltage given mode; reference voltage is a fixed value, given by H00.03.
1：Max power point tracking（MPPT）
Using max power point tracking the given reference voltage, the reference voltage will not stop
changing until the system stable，the maximum power point of this searching mode is limited by range
of H00.04 and H00.05
2：Automatic MPPT
System track the maximum power point automatically, adaptive to different solar panel, can track
and get maximum power point rapidly.
No matter which reference voltage mode adopted, when bus voltage higher than reference
voltage, the target frequency will change to upper limit of PI output frequency; when bus voltage lower
than reference voltage, target frequency will change to lower limit of PI output frequency.
H00.03
Vmpp voltage CVT setting
0～750V
540V
△
When H00.02 is zero, reference voltage will be given by this function code.
H00.04
MPPT mini voltage
reference
0～Max Voltage
500V
×
H00.05
MPPT max voltage
reference
Max Voltage～750V
600V
×
When H00.03 is 1, MPPT voltage will track within H00.04~H00.05, H00.05 must be larger than
H00.04, the smaller the difference between them, the narrower the tracking range, tracking will be
faster. But the voltage point of max power must fall in this range.
H00.06
PID Given Filter Time
0.000～10.000s
0.000s
△
H00.07
PID Response Filter Time
0.000～10.000s
0.000s
△
H00.08
PID Output Filter Time
0.000～10.000s
0.000s
△
H00.09
Ratio Gain Kp1
0.00～100.00
0.10
△
H00.10
Points Time KI
0.00～100.00
0.10
△
H00.11
PID Upper limit of output
frequency
PID Lower limit of output
frequency～100.0%（100.0%
corresponds to the max
frequency）
100.0%
×
H00.12
PID Lower limit of output
frequency
0.0%～PID Upper limit of output
frequency
20.0%
×
