- 33 -
3：AI1+AI2
4：AI1-AI2
5：Max{AI1，AI2}
6：Min{AI1，AI2}
7: DI7/HI pulse input
8：AI3
F13.03
PID setting feedback
range
0～60000
1000
△
F13.04
PID action direction
0: Forward action
0
×
1: Reverse action
F13.05
Filtering time of PID
setting
0.000～10.000s
0.000s
△
F13.06
Filtering time of PID
feedback
0.000～10.000s
0.000s
△
F13.07
Filtering time of PID
output
0.000～10.000s
0.000s
△
F13.08
Proportional gain Kp1
0.0～100.0
1.0
△
F13.09
Integration time Ti1
0.01～10.00s
0.10s
△
F13.10
Differential time Td1
0.000～10.000s
0.000s
△
F13.17
PID offset limit
0.0～100.0%
1.0%
×
F13.18
PID integral property
Unit's digit (Whether to stop
integral operation when the
output reaches the limit)
0: Continue integral operation
1: Stop integral operation
00
×
Ten's digit (Integral separated)
0: Invalid
1: Valid
F13.19
PID differential limit
0.0～100.0%
0.5%
×
F13.20
PID initial value
0.0～100.0%
0.0%
×
F13.21
Holding time of PID
initial value
0.0～6000.0s
0.0s
×
F13.22
PID output frequency
upper limit
PID output frequency lower
limit～100.0%（100.0%
corresponds to maximum
frequency ）
100.0%
×
F13.23
PID output frequency
lower limit
–100.0%～PID output frequency
lower limit
0.0%
×
F13.24
Detection value of
PID feedback loss
0.1～100.0%
0.0%: Not judging feedback loss
0.0%
×
F13.25
Detection time of
PID feedback loss
0.0～30.0s
1.0s
×
F13.26
PID operation at stop
0: No PID operation at stop
0
×
1: PID operation at stop
Group F16 Keys and Display of Keypad Parameters
F16.01
Function of STOP/RST
key
0: STOP/RST key valid only
when under keypad control
1
×
1: STOP/RST key valid under
any run command source
F16.02
Keys locked option
0: Not locked
0
×
1: Full locked
2: Keys locked other than RUN,
STOP/RST
3: Keys locked other than
STOP/RST
