PV series Solar Pumping Inverter
- 38 -
2：Automatic MPPT
H00.03
Vmpp voltage CVT
setting
0～750V
540V
△
H00.04
Mini voltage reference
of MPPT
0～Max Voltage
500V
×
H00.05
Max voltage reference
of MPPT
Max Voltage～750V
600V
×
H00.06
PID Filter Time Given
0.000～10.000s
0.000s
△
H00.07
PID Filter Time
Feedback
0.000～10.000s
0.000s
△
H00.08
PID Filter Time Output
0.000～10.000s
0.000s
△
H00.09
Ratio Gain Kp1
0.00～100.00
0.10
△
H00.10
Points Time KI
0.00～100.00
0.10
△
H00.11
PID Upper Limit of
Output Frequency
PID Lower Limit of Output
Frequency～100.0%（100.0%
corresponds to the max
frequency）
100.0%
×
H00.12
PID Lower Limit of
Output Frequency
0.0%～PID Upper Limit of
Output Frequency
20.0%
×
H00.13
Dormant Delay Time of
Weak light Pre-warning
0.0～6000.0s
600.0s
△
H00.14
Wake-up Delay Time of
Weak Light
0.0～6000.0s
100.0s
△
H00.15
Feedback Channel
Selection of Reservoir
Water Level
0：Null
0
×
1：AI1
2：AI2
3：AI3
H00.16
Clean up the delay time
of full-water pre-warning
0～10000s
600s
△
H00.17
Threshold of reservoir
water level
0.0～100.0
25.0%
△
H00.18
Dormant Delay Time of
Overtank Pre-warning
0～10000s
60s
△
H00.19
Detection of reservoir
hydraulic probe
0.0～100.0
100.0%
△
H00.20
Pre-warning delay time
of pump under-load
0.0～1000.0s
60.0s
△
H00.21
Pre-warning current
0.0～100.0% 0.0：Null
0.0%
△
