13
Raspberry Pi
ā–ˆ www.freenove.com
support@freenove.com ā–ˆ
Hardware interface diagram of RPi 3B+/3B/2B/1B+ is shown below:
Hardware interface diagram of RPi 3A+/A+ is shown below:
GPIO
Connector
Display
Power
HDMI
Connector
Camera
Connector
Audio
Connector
Ethernet
USB
GPIO
Connector
Display
Connector
Power
HDMI
Connector
Camera
Connector
Audio
Connector
USB
Connector
