Chapter 25 Attitude Sensor MPU6050

█ www.freenove.com

support@freenove.com █

Chapter 25 Attitude Sensor MPU6050

In this chapter, we will learn an attitude sensor which integrates accelerometer and gyroscope, MPU6050.

Project 25.1 Read MPU6050

We will read acceleration data and gyroscope data of MPU6050 in this project.

Component List

Raspberry Pi 3B x1

GPIO Expansion Board & Wire x1

BreadBoard x1

MPU6050 x1

Jumper
