Chapter 18 74HC595 & 7-segment display.
188
www.freenove.com █
█ support@freenove.com
Chapter 18 74HC595 & 7-segment display.
In this chapter, we will learn a new component, 7-segment display.
Project 18.1 7-segment display.
We will use 74HC595 to control 7-segment display. and make it display sixteen decimal character "0-F".
Component List
Raspberry Pi 3B x1
GPIO Extension Board & Wire x1
BreadBoard x1
Jumper
74HC595 x1
7-segment display x1
Resistor 220Ω x8
