Chapter 15 Servo

We have learned how to control the speed and steering of the motor before. In this chapter, we will learn a

kind of motor that can rotate to a specific angle, servo.

Project 15.1 Servo Sweep

First, let's learn how to make the servo rotate.

Component List

Raspberry Pi 3B x1

GPIO Expansion Board & Wire x1

BreadBoard x1

Jumper

Servo x1
