195

Chapter 18 74HC595 & 7-segment display.

█ www.freenove.com

support@freenove.com █

Project 18.2 4-Digit 7-segment display

Now, let’s try to control more Digit 7-segment display

Component List

Raspberry Pi 3B x1

GPIO Expansion Board & Wire x1

BreadBoard x1

Jumper

74HC595 x1

PNP

transistor x4

4-Digit 7-segment display x1

Resistor 220Ω

Resistor 1KΩ
