Chapter 19 74HC595 & LED Matrix
208
www.freenove.com █
█ support@freenove.com
Chapter 19 74HC595 & LED Matrix
We have learned how to use 74HC595 to control LEDBar Graph and Seven-SegmentDisplay. And we will
continue to use the 74HC595 to control more LED, LEDMatrix.
Project 19.1 LED Matrix
In this project, we will use two 74HC595 to control a monochrome LEDMatrix (8*8) to make it display some
graphics and characters.
Component List
Raspberry Pi 3B x1
GPIO Extension Board & Wire x1
BreadBoard x1
Jumper
74HC595 x2
8*8 LEDMatrix x1
Resistor 220Ω x8
