Freenove Ultimate Starter Kit User Manual

Chapter 18 74HC595 & 7-segment display.
192
www.freenove.com █
█ support@freenove.com
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
int main( void)
{
int i;
if(wiringPiSetup() == -1){ //when initialize wiring failed,print messageto screen
printf("setup wiringPi failed !");
return 1;
}
pinMode(dataPin,OUTPUT);
pinMode(latchPin,OUTPUT);
pinMode(clockPin,OUTPUT);
w hile(1){
for(i=0;i<sizeof(num);i++){
digitalWrite(latchPin,LOW);
_shiftOut(dataPin,clockPin,MSBFIRST,num[i]);//Output the figures and the
highest level is transfered preferentially.
digitalWrite(latchPin,HIGH);
delay(500);
}
for(i=0;i<sizeof(num);i++){
digitalWrite(latchPin,LOW);
_shiftOut(dataPin,clockPin,MSBFIRST,num[i] & 0x7f);//Use the "&0x7f" to
display the decimal point.
digitalWrite(latchPin,HIGH);
delay(500);
}
}
r eturn 0;
}
First, put encoding of “0”-“F” into the array.
unsigned char
num[]={0xc0,0xf9,0xa4,0xb0,0x99,0x92,0x82,0xf8,0x80,0x90,0x88,0x83,0xc6,0xa1,0x86,0x8e};
In the “for” cycle of loop() function, use 74HC595 to output contents of array “num” successively.
SevenSegmentDisplay can correctly display the corresponding characters. Pay attention to that in shiftOut
function, the transmission bit, flag bit highest bit will be transmitted preferentially.
for(i=0;i<sizeof(num);i++){
digitalWrite(latchPin,LOW);
_shiftOut(dataPin,clockPin,MSBFIRST,num[i]);//Output the figures and the
highest level is transfered preferentially.
digitalWrite(latchPin,HIGH);
delay(500);
}
