So, we can use just 4 pins to control LCD1602 with 16 pins easily through I2C interface.

In this project, we will use I2CLCD1602 to display some static characters and dynamic variables.

Component List

Raspberry Pi 3B x1

GPIO Extension Board & Wire x1

BreadBoard x1

Jumper

I2C LCD1602 Module x1
