Chapter 27 Solder Circuit Board

█ www.freenove.com

support@freenove.com █

Test circuit

Connect the circuit board to power supply (3~5V). You can use Raspberry Pi board or battery box as the

power supply.

Press the push button after connecting the power, and then the buzzer will make a sound.

Anode

Cathode

Tear the label off
