FGR2-PE Wirelss Data Transceiver
LUM0024AB Rev A
Pin Assignment Signal Definition
7 RTS Request to Send Input The transceiver does not recognize RTS for flow
control. RTS is used as a control line in RTS/CTS
mode.
8 CTS Clear to Send Output This signal is used to tell the system device connected
to the transceiver that the transceiver is ready to
receive data. When asserted, the transceiver will
accept data, when de-asserted the transceiver does
not accept data. This should always be used for data
rates above 38.4 KB or a risk of lost data may occur if
an RF link is not very robust.
9 GND Ground Signal return for all signal lines shared with Pin 5
98
