User Manual and Reference Guide
LUM0024AB Rev A
Factory Default Settings
The Plus-style transceivers ship from the factory with the following default settings:
Parameter Default Setting
Serial Setup (1 and 2) Parameter
Mode TCP Server
TCP Server Port Setup 1: 7000
Setup 2: 7001
TCP Server Alarm Disabled
TCP Server Alarm IP & Port Setup 1: 0.0.0.0 : 8000
Setup 2: 0.0.0.0:8001
TCP Server Maintain/Drop Link Disabled
TCP Server Alarm Retry Limit (Attempts) 0
TCP Server Inactivity Timeout (Seconds) 0
TCP Client IP Address & Port Setup 1: 0.0.0.0 : 9000
Setup 2: 0.0.0.0 : 9001
UDP Local IP Port Setup 1: 6000
Setup 2: 6001
UDP Power Up Dest. IP & Port 0.0.0.0 : 0
Multicast Address & Port Setup 1: 225.0.0.38 : 11111
Setup 2: 225.0.0.38 : 22222
Baud Rate 19200
Data Bits 8
Parity None
Stop Bits 1
Flow Control None
CD Mode Normal
Interface RS232
Modbus RTU Enabled
IPSetup Parameter
IP Address 192.168.111.100
Subnet Mask 255.255.255.0
101
