SGC ROTARY SCREW COMPRESSOR
INSTALLATION
Installation
DESIGN LIMITS
General information for all of the models is provided below.
Please see CoolWare to determine the limits for a
specic application.
SGC/SGX compressor models are primarily designed for
connecting to an electric drive motor using a tunnel mount.
If the application requires it, the compressor can also be
driven with a foot-mounted motor. The tunnel mount en-
sures proper alignment of the compressor and motor so
that the shaft seal and coupling will operate properly. The
rotor and bearing design set limitations must not be ex-
ceeded (See CoolWare). Refer to Johnson Controls - Frick
Compressor Control Panel instruction 090.020-M for addi-
tional information on setpoint limits.
For proper piping, also see the Frick package manual,
070.610-IOM for RWF II rotary screw compressor units,
Models 100 through 1080.
OUTLINE DIMENSIONS
Drawings for reference only can be found on the following
pages. Complete dimensions and access connections can
be found on the outline drawings.
SGC 1913 & 1918 DWG# 534E0677
SGC 2313 & 2317 DWG# 534E0700
SGC 2321 DWG# 534E0714
SGC 2813 & 2817 DWG# 534E0749
SGC 2821 DWG# 534E0768
SGC 2824 DWG# 534E0973
SGCH 3511 & SGCB 3511 DWG# 534E0966
SGCH 3515 & SGCB 3515 DWG# 534E0971
SGCH 3519 & SGCB 3519 DWG# 534E0972
SGXH 3519 & SGXB 3519/3524 DWG# 534E1405
SGXH 4013, 4018 & 4021 DWG# 534E1403
If you do not have these drawings, please request any you
require by contacting Johnson Controls - Frick sales.
