070.250-IOM1 (NOV 2013)
Page 26
TDS_ Rotary Screw Compressor
Maintenance
Date: __________________________________________ Sales Order Number: ________________________________
End User: _______________________________________ Installing Contractor: ________________________________
Address: __________________________________________ Service Technician: __________________________________
Equipment ID (As in Microlog): ____________________
Compressor Model Number: __________________________
Compressor Serial Number: __________________________
Unit Serial Number: _________________________________
National Board Number: _____________________________
Running Hours: _____________________________________
Manufacturer and Size of Coupling: ____________________
Motor Manufacturer: RAM ____________________________
Motor Serial Number: ________________________________
RPM: ________ Frame Size: ___________ H.P. __________
Refrigerant:
Ambient Room Temperature: ____________°F
Operating Conditions:
Vibration data sheet
Suction Discharge Oil Separator Slide valve position %
Press # Press # Press # Temp °F Vi Ratio
Temp °F Temp °F Temp °F F.L.A. %
Compressor Inboard
(Coupling End)
Vertical Direction
____.____ IPS Overall
Compressor Inboard
(Coupling End Male)
Axial Direction
____.____ IPS Overall
Motor Inboard (Coupled End)
Horizontal _______ . ______ IPS Overall
Vertical _______ . ______ IPS Overall
Axial _______ . ______ IPS Overall
Compressor Outboard
(Nondrive End)
Vertical Direction
____.____ IPS Overall
Compressor Inboard
(Coupling End Female)
Axial Direction
____.____ IPS Overall
Motor Outboard (Noncoupled End)
Horizontal _______ . ______ IPS Overall
Vertical _______ . ______ IPS Overall
Axial _______ . ______ IPS Overall
Soft Foot Soft Foot
Soft Foot Soft Foot
Final Hot Alignment
Total Thickness of Shims Added
Face
Rim
To Next Page
