SECTION 4 - COMPONENT TEAR DOWN
Front Panel
The washer front panel is held in place by two lower screws,
hooking tabs to the side panels, and a locating dowel to the
top panel.
To remove the washer front panel:
1. Disconnect the washer from electrical source
2. Remove the two lower screws with a #2 square bit
screwdriver.
3. Slide the panel downward to disengage the tabs from the
side panels and pull the panel away from the unit.
4 - 5
