SECTION 6 - PUSH BUTTON SELECTION WASHER TECHNICAL DATA
ERROR
NOTIFICATION
14 CYCLE
WASHER
FIRST DIGIT OF ERROR CODE
2 SECOND
PAUSE BE-
FORE SECOND
DIGIT
SECOND DIGIT OF ERROR CODE
BEEPS
SHORT PAUSE
BETWEEN EACH BEEP
SHORT PAUSE
BETWEEN EACH BEEP
1 BEEP = 1
2 BEEPS = 2
3 BEEPS = 3
4 BEEPS = 4
5 BEEPS = 5
6 BEEPS = 6
7 BEEPS = 7
8 BEEPS = 8
9 BEEPS = 9
10 BEEPS = A
11 BEEPS = B
12 BEEPS = C
13 BEEPS = D
14 BEEPS = E
15 BEEPS = F
16 BEEPS = G
17 BEEPS = H
18 BEEPS = I
1 BEEP = 1
2 BEEPS = 2
3 BEEPS = 3
4 BEEPS = 4
5 BEEPS = 5
6 BEEPS = 6
7 BEEPS = 7
8 BEEPS = 8
9 BEEPS = 9
10 BEEPS = A
11 BEEPS = B
12 BEEPS = C
13 BEEPS = D
14 BEEPS = E
15 BEEPS = F
16 BEEPS = G
17 BEEPS = H
18 BEEPS = I
LED ON MAIN
BOARD CON-
TROL INSIDE
CABINET
SHORT PAUSE
BETWEEN EACH FLASH
SHORT PAUSE
BETWEEN EACH FLASH
1 FLASH = 1
2 FLASHES = 2
3 FLASHES = 3
4 FLASHES = 4
5 FLASHES = 5
6 FLASHES = 6
7 FLASHES = 7
8 FLASHES = 8
9 FLASHES = 9
10 FLASHES = A
11 FLASHES = B
12 FLASHES = C
13 FLASHES = D
14 FLASHES = E
15 FLASHES = F
16 FLASHES = G
17 FLASHES = H
18 FLASHES = I
1 FLASH = 1
2 FLASHES = 2
3 FLASHES = 3
4 FLASHES = 4
5 FLASHES = 5
6 FLASHES = 6
7 FLASHES = 7
8 FLASHES = 8
9 FLASHES = 9
10 FLASHES = A
11 FLASHES = B
12 FLASHES = C
13 FLASHES = D
14 FLASHES = E
15 FLASHES = F
16 FLASHES = G
17 FLASHES = H
18 FLASHES = I
ALPHA-NUMER-
IC DISPLAY ON
CONSOLE
N/A
Reading Error Codes
NOTIFICATION TYPE
COMMUNICATION
REPETITION OF COMMUNICATION SEQUENCE
BEEPS
5 BEEPS, BRIEF PAUSE, 12 BEEPS
SEQUENCE COMMUNICATED ONCE. REMAINS SILENT UNTIL CYCLE SELEC-
TOR IS PRESSED FOR NEXT CODE.
LED ON MAIN BOARD
CONTROL INSIDE
CABINET
5 FLASHES, BRIEF PAUSE, 12 FLASHES
SEQUENCE REPEATS AFTER 2 SECOND PAUSE. CONTINUES REPEATING
UNTIL CYCLE SELECTOR IS PRESSED FOR NEXT CODE.
ALPHA-NUMERIC DIS-
PLAY ON CONSOLE
DISPLAY REMAINS ON UNTIL CYCLE SELECTOR IS PRESSED FOR NEXT
CODE.
Error Code Example: “E5C - Voltage too high on main board”
1. Error codes can only be read while in Diagnostic Mode.
2. Most recent error code will be communicated fi rst.
3. Press the cycle selector knob to cycle (one-at-a-time) through the fi ve most recent error codes.
4. “00” signifi es no error code and is accompanied by no beeps and no LED fl ashes.
5. To clear all error codes, press and hold the cycle selector knob for 5 seconds.
