4.2.2 Cleaning
The ash drawers (P4 Pellet 15-25) or ash container (P4 Pellet 32-105) must be
emptied at intervals according to energy requirements and pellet quality. The grate
and combustion chamber should also be checked at these intervals for dirt.
Emptying the ash drawers (for P4 Pellet 15/20/25)
1.
2.
3.
4.
5.
6.
❒
Open the insulated door and position the ash drawer below the ash doors to catch
any ash that might overflow
❒ Open ash doors
❒ Pull the ash drawer out slightly
➥ This pushes the ash lying in front of the drawer into the ash bowl
❒ Put the transport cover on as illustrated and pull out the ash drawer until the
transport cover engages
❒ Take the ashcan to the emptying point and empty it
➥ Push up the locking lever to remove the transport cover.
Boiler Servicing
4
Inspection and cleaning
Operating Instructions P4 Pellet | B0870417_en 27
