Froling P4 Pellet - Page 6

Ash removal unit P4 Pellet 8-25
6 Ash drawer - heat exchanger
7 Ash drawer - combustion chamber
8 Ash drawer
Ash removal unit P4 Pellet 32-105:
9 Ash container - heat exchanger
10 Ash container - combustion chamber
11 Ash screw and rotary agitator of the automatic heat exchanger cleaner
12 Ash screw and rotary agitator of the combustion chamber ash removal unit
13 Lever of the ash box lock
1
General
P4 Pellet product overview
6 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com
