Cleaning the flue gas recirculation (AGR) (optional)

(Item D ⇨ See "Periodic inspection and cleaning" [page 38])

❒ Remove the pipe insulation from the inspection cover

❒

Remove the inspection cover and clean the pipes of the flue gas recirculation unit

with a brush

Boiler Servicing

Inspection and cleaning

Operating Instructions TX 200-250 | B1060217_en 43
