6
4 APPROPRIATE USE
The tool model P300 has been designed to strap packages with plastic strapping exclusively.
A different or exceeded use is not appropriate.
For example the running idle use (without strap) is a not appropriate use.
FROMM HOLDING AG does not warrant any damages caused by non-appropriate use of the tool.
Appropriate use also includes:
• Regarding of all directions in the operation manual.
• Regarding of control and maintenance instructions.
Attention!
Electromagnetic fields with high intensity may affect the proper function of the device.
If this occurs, operate the machine at a different location, or contact our customer service.
5 TECHNICAL DATA
5.1 Description of the tool
The tool model P300 has been designed to strap packages with plastic strapping. The plastic strapping is fed
around the package manually or in combination with a strap feeder. The straps are inserted in the tool,
automatically tensioned, sealed by friction welding and separated.
5.2 Sound information
The A-weighted equivalent continuous sound level at the work place of the machine operator is
typical 82 dB (A).
This value was determined according to DIN 45 635 T3 (11.85).
5.3 Vibration information
The weighted effective value of the acceleration typically amounts to less than 4,1 m/s
2
.
This value was determined according to DIN EN 28 662 T1 (01.93).
5.4 Strap tension
Tensioning force*: Max. 1600 N / 360 lbs
Tensioning speed*: approx. 170 mm / s
Joint strength*: approx. 75% of the tensile strength of the plastic strap
Strap qualities: PET (Polyester), see chart of types.
PP (Polypropylen), see chart of types.
Strap dimensions: 10 - 16 x 0.4 - 0.8 mm, see chart of types.
*These values are depending on the strap quality.
5.5 Dimensions without suspension bracket
Tool: Package:
Length: 290 mm / 11.4" 360 mm / 14.2"
Width: 90 mm / 3.5" 400 mm / 15.8"
Height: 250 mm / 9.8" 110 mm / 4.3"
Weight: 3.9 kg / 8.6 lbs 0.8 kg / 1.8 lbs
