7-3-1 ELECTRIC CONTROL GROUP T6-8-20004
(For TP-601D1) T6-8-20012
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
T6-8-20004 Electric Control Group (For 110V) 1
T6-8-20012 Electric Control Group (For 220V/ 1
230V/240V)
1 T6-8-21110 Box 1
2 T6-8-21120 Cover 1
3 LA-20086 Label 1
4 T6-6-30041 Transformer 1
5 T6-8-20150 P.C.Board (For 50HZ, 1Phase) 1
6 T6-8-20160 P.C.Board (For 60HZ, 1Phase) 1
7 T6-6-30047 EMI Filter 1
8 T6-6-30022 Connector (Power) 1
9 T6-6-30018 Connector (Heater) 1
10 T5-4-10231
Variable Resistor (5K)(∮3)
1
11 T5-4-10221 Knob 1
12 T5-4-10160 Fuse Holder 6
13 T6-6-30033 Fuse (5A)(For 220V/230V/240V) 2
T6-6-30133 Fuse (10A)(For 110V) 1
14 T6-6-30034 Fuse (7A)(For 220V/230V/240V) 1
T6-6-30133 Fuse (10A)(For 110V) 1
15 T6-6-30031 Fuse (2A) 1
16 T6-6-30036 Fuse (1A) 1
17 T6-6-30031 Fuse (2A)(For 220V/230V/240V) 1
T6-6-30032 Fuse (3A)(For 110V) 1
18 T6-8-20005 Electric Control Group (For 110V) 1
T6-8-20013 Electric Control Group (For 220V/ 1
230V/240V)
19 TMS0306 TMS, M3x6 8
20 TMS0508 TMS, M5x8 4
21 PMS0306 PMS, M3x6 4
22 PMS0412 PMS, M4x12 2
23 SW04 SW, M4 3
24 HN04 HN, M4 3
25 T6-8-20440 Wire Ass'y X1 (For Motor M1) 1
26 T6-8-20450 Wire Ass'y X2 (For Motor M2) 1
27 T6-8-20460 Wire Ass'y X3 (For Motor M3) 1
