7-3-1 ELECTRIC CONTROL GROUP T6-8-20004
(For TP-601D1) T6-8-20012
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
28 T6-8-20470 Wire Ass'y X4 (For Motor M5) 1
29 T6-8-20480 Wire Ass'y X5 (For Motor M5-1) 1
30 T6-1-50680 Proximity Sensor X6 (For LS6, SFS) 2 SEE PAGE 5
31 T7-1-20350 Photo Eye X7 (PH1) 1 SEE PAGE 17
32 T6-8-20510 Wire Ass'y X8 (For Control Panel) 1
33 T6-8-20431 CPU 1
34 T6-8-20520 Wire Ass'y X9 (For LS4/LS5/ 1
Foot Switch)
35 T6-8-20530 Wire Ass'y X10 (For T1) 1
36 T6-1-10680
Proximity Sensor X11,X12 (For LS2, LS3)
2 SEE PAGE 2
38 T6-8-20560
Wire Ass'y X13 (For Weld Cooling Time)
1
39 T6-8-20570 Wire Ass'y X14 (For BRK) 1
40 T7-5-42660 Nut 1 SEE PAGE 17
41 T6-8-20580 Earth Plate (4P) 1
42 TMS0412 TMS, M4x12 1
45 PMS0310 PMS, M3x10 2 SEE PAGE 5
46 PMS0320 PMS, M3x20 4 SEE PAGE 2
47 PMS0325 PMS, M3x25 2 SEE PAGE 5
50 SW03 SW, M3 8
SEE PAGE 2, 5
-92-
To Next Page
