7-3-2 ELECTRIC CONTROL GROUP T6-8-21005
(For TP-601D3)
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
1 T6-8-21110 Box 1
2 T6-8-21120 Cover 1
3 LA-20090 Label 1
4 T6-6-30041 Transformer 1
5 T6-8-21150 P.C.Board (For 50HZ, 3Phase) 1
6 T6-8-21160 P.C.Board (For 60HZ, 3Phase) 1
7 T6-6-30047 EMI Filter 1
8 T6-8-21180 Connector (Power) 1
9 T6-6-30018 Connector (Heater) 1
10 T5-4-10231 Variable Resistor (5K) 1
11 T5-4-10221 Knob 1
12 T5-4-10160 Fuse Holder 6
13 T6-6-30034 Fuse (7A) 3
14 T6-6-30031 Fuse (2A) 2
15 T6-6-30036 Fuse (1A) 1
16 TMS0306 TMS, M3x6 4
17 TMS0508 TMS, M5x8 4
18 T6-8-21006 Electric Control Group 1
19 T6-8-21290 Transformer (For 380V/400V/ 1
415V Only)
20 T6-8-21300 Transformer Cover (For 380V/400V/ 1
415V Only)
21 HBS0510 HBS, M5x10 3
22 PW05 PW, M5 3
23 HBS0512 HBS, M5x12 1
24 T6-6-30200 Earth Plate (3P) 1
25 TMS0408 TMS, M4x8 1
26 PMS0306 PMS, M3x6 4
27 PMS0412 PMS, M4x12 2
28 SW04 SW, M4 3
29 HN04 HN, M4 1
30 T6-8-21452 Wire Ass'y X1 (For Motor M1) 1
31 T6-8-21453 Wire Ass'y X2 (For Motor M2) 1
32 T6-8-21454 Wire Ass'y X3 (For Motor M3) 1
33 T6-8-20470 Wire Ass'y X4 (For Motor M5) 1
34 T6-8-20480 Wire Ass'y X5 (For Motor M5-1) 1
