7-3-2 ELECTRIC CONTROL GROUP T6-8-21005
(For TP-601D3)
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
35 T6-1-50680 Proximity Sensor (For LS6, SFS) 2 SEE PAGE 5
36 T7-1-20350 Photo Eye (PH1) 1 SEE PAGE 17
37 T6-8-20510 Wire Ass'y X8 (For Control Panel) 1
38 T6-8-20520 Wire Ass'y X9 (For LS4/LS5/Foot 1
Switch)
39 T6-8-20530 Wire Ass'y X10 (For T1) 1
40 T6-1-10680 Proximity Sensor (For LS2, LS3) 2 SEE PAGE 2
42 T6-8-20560
Wire Ass'y X13 (For Weld Cooling Time)
1
43 T6-8-20570 Wire Ass'y X14 (For BRK) 1
44 T6-8-21451 CPU 1
45 T7-5-42660 Nut 1 SEE PAGE 17
46 T6-8-20580 Earth Plate (4P) 1
51 TMS0412 TMS, M4x12 1
55 PMS0310 PMS, M3x10 2 SEE PAGE 5
56 PMS0320 PMS, M3x20 4 SEE PAGE 2
57 PMS0325 PMS, M3x25 2 SEE PAGE 5
60 SW03 SW, M3 8
SEE PAGE 2, 5
-95-
