Micro Switch(LS4)
M6 Screw
T7-3-10190
Fig A
If you have moved the LS4 Micro Switch to the left up to the bottom but you still
do not have enough P.P. strap in the accumulator box, you can loosen nut E and
turn the bolt D ccw increase the amount of P.P.strap in the accumulator box. finally
D
E
b-1 Fig A :
T7-3-10200
(4) Amount of strap in Accumulator Box
b. (TP-601L)
tighten the nut E.
Less
More
